Benefits

·         Robust design that works out of the box in a wide range of environments and applications

·         High speed color and monochrome direct-to-card printing

·         High capacity ribbons result in low cost-per-card and minimizes the number of ribbon changes required

Standard Features

·         300 dpi/11.8 dots per mm print resolution

·         USB 2.0 and Ethernet 10/100 connectivity

·         Microsoft® Windows-certified drivers

·         10-50 mil auto-adjusting card feeder

·         200-card capacity feeder (30 mil)

·         15-card reject hopper (30 mil)

·         100-card output hopper (30 mil)

·         Manual card feed capability

·         21-character x 6-line LCD operator display with configurable soft keys

·         Kensington® physical lock slot

·         Two-year unlimited warranty on printer and printhead

Optional Features

·         Single and dual-sided laminator

·         Lockable enclosures and card feeder

·         Extended product warranty programs

·         802.11 b/g wireless connectivity

·         Duo-Print dual-sided printing upgrade kit

·         1D integrated barcode reader

Encoding Options

·         High and low coercivity magnetic stripe encoder

·         Combined MIFARE® ISO 14443 A & B contactless and ISO 7816 Contact Encoder

·         ISO 7816 Smart Card Contact Station for third party external contact encoders

·         Gen 2 UHF RFID encoder

Printing and Laminating specifications

·         Color dye sublimation or monochrome thermal transfer printing

·         Single- and dual-sided printing

·         Edge-to-edge printing on standard CR-80 media

·         Simultaneous printing, encoding, and laminating capability

·         One-pass single- and dual-sided wasteless lamination

·         1375 cards/hour monochrome single-sided or 555 cards/hour dual-sided printing

·         300 cards/hour full-color YMCKO single-sided printing

·         225 cards/hour full-color YMCKOK dual-sided printing

·         270 cards/hour full-color YMCKO single-sided printing with lamination

·         200 cards/hour full-color YMCKOKO dual-sided printing with lamination

Supplies Specifications

True Colours® ix Series™ ribbons:

·         YMCKO: 250 or 750 images/roll

·         YMCKOK: 250 or 750 images/roll

·         YMCUvK: 750 images/roll

·         Black monochrome: 2500 or 5000 images/roll

·         White monochrome: 4000 images/roll

·         Red, blue, gold, sliver monochrome: 5000 images/roll

·         1/2 panel YMCKO: 1250 images/roll

·         KdO and KrO: 2000 images/roll

·         WrKr: 2000 images/roll

·         Scratch-off Gray: 3250 images/roll

True Secure™ i series laminates:

·         Linerless waste-free 1.0 mil top and bottom laminate: 750 images/roll

·         Laminate types: clear, magnetic stripe, smart card, and holographic wallpaper designs

·         Custom laminates with registered or wallpaper holographic images available

·         Card cleaning rollers are included with each ribbon carton

·         Specially designed cleaning supplies simplify preventative maintenance

NOTE: For optimum print quality and printer performance, use of Zebra genuine supplies is recommended.

Card specifications/compatibility

·         Card Thickness: 10 – 50 mil (0.25 – 1.27mm)

·         Card Thickness for lamination: 30 mil (0.76 mm) only

·         Card Size: CR-80, ISO 7810 format, Type ID-1

·         Card Material: PVC and composite, PET, PET-G, PET-F, and Teslin® composite

·         Technology Cards: contact and contactless smart cards

·         Specialty cards: adhesive backed, transparent (IR-Blocker), signature panel, and select key-tag types

Operating Characteristics

·         Operating Temperature: 59º F/15ºC to 95º F/35ºC

·         Storage Temperature: 23º F/-5ºC to 158º F/70ºC

·         Operating Humidity: 20% to 80% inclusive, non-condensing

·         Storage Humidity: 10% to 90% inclusive, non-condensing

·         Media should be stored away from direct sunlight, between +5ºC and +20ºC, and between 30% to 50% relative humidity

Electrical Specifications

·         Auto-switching single-phase AC power

·         90V~264V AC and 47–63Hz (50-60Hz nominal)

·         FCC Class A

Physical Characteristics

·         Height: 12.0" (306mm)

·         Width (printer only): 27.5" (699mm)

·         Width (printer with laminator): 38.0" (964mm)

·         Depth: 10.9" (277mm)

·         Weight (printer only): 26.9 lbs (12.2 kg)

·         Weight (printer with laminator): 39.5 lbs (17.9 kg)

Software

·         ZMotif SDK support and sample code

·         Microsoft Windows-certified printer drivers with Toolbox utility features: Windows® XP (32 bit), Windows Vista® (32 and 64 bit), Windows Server® 2003 (32 bit), Windows 7® (32 and 64 bit), Windows Server 2008 (32 and 64 bit), Windows 8®, Win8 Pro (32 and 64 bit)Windows Server 2012 (64 bit)

·         CardStudio card design and issuance software

·         Zebra Virtual PrintWare software support
